Specifications

• Engine

  add remove
  • Engine:
    Standard
  • Engine Type:
    Parallel Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    47.4
  • Valves:
    8
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    SOHC
  • Displacement (cc):
    648
  • Compression ratio:
    9.5:1
• Transmission

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Overdrive:
    No
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    87.2
  • Width (in):
    33.7
  • Height (in):
    45.7
  • Wheelbase (in):
    57.5
  • Ground Clearance (in):
    7.2
  • Wet Weight (lbs):
    471.8
  • Engine Displacement to Weight (cc):
    1.37
  • Fuel Capacity (gal):
    3.6
  • GVWR (lbs):
    881.8
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    2
  • Front Suspension Size (in):
    1.7
  • Front Travel (in):
    5.1
  • Rear Suspension Brand Name:
    Showa®
  • Rear Travel (in):
    4.5
  • Front Suspension Brand Name:
    Showa®
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Front Tire (Full Spec):
    100/90-19 M/C 57H MRF NYLOREX-F
  • Rear Tire (Full Spec):
    140/80 R17 M/C 69H MRF NYLOREX-X
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Front Brake Diameter (in):
    12.6
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    10.6
  • Brake Brand Name:
    Brembo®
