Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    1-cylinder, 4-stroke SOHC
  • Capacity:
    249.9 cc
  • Bore:
    3.1 in
  • Stroke:
    2.1 in
  • Compression:
    14.4
  • Max Power:
    30.6 kW
  • Max Torque:
    20.5 ft-lb
  • System:
    Dellorto 44mm Cable Throttle, EFI
  • Exhaust:
    Single Silencer
  • Final Drive:
    13/52
  • Clutch:
    Aluminium separate basket Wet; Multiple Disc Hydraulic
  • Gearbox:
    6 Speed
• Chassis

  add remove
  • Frame:
    Aluminium, Spine
  • Swingarm:
    Aluminium Fabrication
  • Front Wheel:
    21" x 1.6"
  • Rear Wheel:
    18” x 2.15”
  • Front Tyre:
    90/90 - 21
  • Rear Tyre:
    140/80 - 18
  • Front Suspension:
    KYB 48mm Coil Spring Fork, Compression/Rebound Adjustment, 300mm Travel
  • Rear Suspension:
    KYB Coil, Compression Adjustment (High and Low Speed), Rebound Adjustment, 313mm Travel
  • Front Brake:
    Single, Ø260 Galfer Disc, Brembo, 2xØ24 pistons, floating caliper
  • Rear Brake:
    Single, Ø220 Galfer Disc, Brembo, 1xØ26 pistons, floating caliper
  • Instrument Display and Functions:
    Speedo, Multi-Function Switch Cubes
• Dimensions & Weights

  add remove
  • Width Handlebars:
    32.9 in
  • Height Without Mirror:
    49.8 in
  • Seat Height:
    37.6 in
  • Wheelbase:
    58.6 in
  • Rake:
    26.8 º
  • Trail:
    4.4 in
  • Tank Capacity:
    2.2 gal
  • Wet Weight:
    114.2 Kg
