Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel-twin
  • Capacity:
    900 cc
  • Bore:
    3.3 in
  • Stroke:
    3.1 in
  • Compression:
    11:1
  • Max Power:
    47.8 kW / 7500 rpm
  • Max Torque:
    59.0 ft-lb / 3800 rpm
  • System:
    Multipoint fuel injection with electronic throttle control.
  • Exhaust:
    Brushed stainless steel 2 into 2 exhaust system with twin black painted silencers, with brushed stainless steel end caps
  • Final Drive:
    X-ring chain
  • Clutch:
    Wet, multi-plate, slip
  • Gearbox:
    5 speed
• Chassis

  add remove
  • Frame:
    Tubular steel, with steel cradles
  • Swingarm:
    Twin-sided, fabricated aluminium
  • Front Wheel:
    Cast aluminium alloy, 8-spoke, 18 x 2.75 in
  • Rear Wheel:
    Cast aluminium alloy, 8-spoke, 17 x 4.25 in
  • Front Tyre:
    100/90-18
  • Rear Tyre:
    150/70 R17
  • Front Suspension:
    Ø 43mm upside-down Marzocchi forks, 120 mm wheel travel
  • Rear Suspension:
    Twin Marzocchi RSUs with external reservoirs and adjustable preload, 116 mm wheel travel
  • Front Brake:
    Single Ø 320mm floating disc, Triumph branded four-piston radial caliper, OCABS
  • Rear Brake:
    Single Ø 255mm fixed disc, Nissin 2-piston floating caliper, OCABS
  • Instrument Display and Functions:
    LCD multi-function instruments with integrated colour TFT screen
• Dimensions & Weights

  add remove
  • Width Handlebars:
    30.6 in
  • Height Without Mirror:
    43.9 in
  • Seat Height:
    30.7 in
  • Wheelbase:
    56.5 in
  • Rake:
    24.9 º
  • Trail:
    4.1 in
  • Tank Capacity:
    3.2 gal
  • Wet Weight:
    216 kg
• Fuel Consumption

  add remove
  • Fuel Consumption:
    4.0L/100km
  • CO₂ Figures:
    EURO 5 CO2 emissions and fuel consumption data are measured according to regulation 168/2013/EC. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving results.
• Features

  add remove
  • Lighting:
    LED headlight with DRL
• Technology

  add remove
  • Riding modes:
    Two riding modes – Road and Rain
  • Instruments:
    LCD multi-function instruments with integrated colour TFT screen
  • ABS:
    Optimised Cornering ABS and traction control
