Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
  • Capacity:
    660 cc
  • Bore:
    2.9 in
  • Stroke:
    2.0 in
  • Compression:
    11.95:1
  • Max Power:
    59.6 kW / 10250 rpm
  • Max Torque:
    47.2 ft-lb / 6250 rpm
  • System:
    Multipoint sequential electronic fuel injection with electronic throttle control
  • Exhaust:
    Stainless steel 3 into 1 header system with low single sided stainless steel silencer
  • Final Drive:
    X-ring chain
  • Clutch:
    Wet, multi-plate, slip and assist
  • Gearbox:
    6 speed
• Chassis

  add remove
  • Frame:
    Tubular steel perimeter frame
  • Swingarm:
    Twin-sided, fabricated steel
  • Front Wheel:
    Cast aluminium alloy 5 spoke, 17 x 3.5 in
  • Rear Wheel:
    Cast aluminium alloy 5 spoke, 17 x 5.5 in
  • Front Tyre:
    120/70R17
  • Rear Tyre:
    180/55R17
  • Front Suspension:
    Showa 41mm upside down separate function big piston (SFF-BP) forks, 120mm Wheel travel
  • Rear Suspension:
    Showa monoshock RSU, with preload adjustment, 130mm Wheel travel
  • Front Brake:
    Twin Ø310mm discs, Nissin 2-piston sliding calipers, OCABS
  • Rear Brake:
    Single Ø255mm fixed disc, single piston sliding caliper, OCABS
  • Instrument Display and Functions:
    LCD Multifunction Instruments with integrated colour TFT screen
• Dimensions & Weights

  add remove
  • Width Handlebars:
    31.3 in
  • Height Without Mirror:
    42.9 in
  • Seat Height:
    31.7 in
  • Wheelbase:
    55.2 in
  • Rake:
    24.6
  • Trail:
    4.2 in
  • Tank Capacity:
    3.7 gal
  • Wet Weight:
    190kg
• Fuel Consumption

  add remove
  • Fuel Consumption:
    EURO 5 CO2 emissions and fuel consumption data are measured according to regulation 168/2013/EC. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving results.
• Features

  add remove
  • Clutch:
    Slip and assist clutch
• Technology

  add remove
  • Riding modes:
    3 riding modes – sport, road, rain
  • ABS:
    Optimised cornering ABS and traction control
