2023 Speed Triple 1200 RR Bond Edition

Specifications

• Engine & Transmission

  add remove
  • Engine Type
    Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
  • Capacity
    1160 cc
  • Bore
    3.5 in
  • Stroke
    2.4 in
  • Compression
    13.2:1
  • Max Torque
    92.2 ft-lb
  • System
    Multipoint sequential electronic fuel injection with electronic throttle control
  • Exhaust
    Multipoint sequential electronic fuel injection with electronic throttle control
  • Final Drive
    X-ring chain
  • Clutch
    Wet, multi-plate, slip & assist
  • Gearbox
    6 speed
• Chassis

  add remove
  • Frame
    Aluminium twin spar frame, bolt-on aluminium rear subframe
  • Swingarm
    Aluminium, single-sided
  • Front Wheel
    Cast aluminium, 17 x 3.50 in
  • Rear Wheel
    Cast aluminium, 17 x 6.00 in
  • Front Tyre
    Metzeler Racetec RR K3 120/70 ZR17
  • Rear Tyre
    Metzeler Racetec RR K3 190/55 ZR17
  • Front Suspension
    Öhlins 43 mm NIX30 upside down forks with adjustable preload, rebound and compression damping, 120 mm travel.
  • Rear Suspension
    Öhlins TTX36 twin tube monoshock with preload, rebound and compression damping, 120 mm rear wheel travel.
  • Front Brake
    Twin 320mm floating discs. Brembo Stylema monobloc calipers, OC-ABS, radial master cylinder with separate reservoir, span & ratio adjustable.
  • Rear Brake
    Single 220mm disc. Brembo twin piston caliper, OC-ABS. Rear master cylinder with separate reservoir.
• Dimensions & Weights

  add remove
  • Width Handlebars
    31.2 in
  • Height Without Mirror
    42.9 in
  • Seat Height
    32.7 in
  • Wheelbase
    56.9 in
  • Rake
    23.9 °
  • Trail
    4.1 in
  • Tank Capacity
    4.1 gal
• Color options

  add remove
  • Granite Grey / Storm Grey
